Storage Tanks

Domestic Hot and Cold Water

RECO can build a storage tank to suit any demand, water type, or area classification. When you specify and install a RECO storage tank, you will have confidence in knowing that the owner will be provided with a long lasting, trouble‐ free source of hot water.

Specifications & Ratings

Materials
ASTM SA-516-70 carbon steel tanks as standard
Specifications
Designed to ASME B & PV Code, Section VIII, Division I
Connections
All connections over 2½” are ANSI 150 lb. RFSO flanges
Interiors
Cleaned to SSPC-SP 3, with NSF 61 compliant lining
Exteriors
Sandblasted per SSPC-SP 6 and coated with a red oxide primer
Ratings
150 PSIG max design pressure, 250 °F max design temperature

DOMESTIC HOT AND COLD WATER STORAGE TANKS

RECO Commercial Systems’ storage tanks are designed for storing potable water. Standard tanks are carbon steel vessels with an interior lining to prevent corrosion at higher temperatures. The lining is a 5/8” layer of cement, manufactured from NSF certified materials. It provides excellent, long‐term protection and is fully field repairable. Unlike glass linings, which are not field repairable, a sacrificial anode for corrosion protection is not required. All tank openings are non‐ferrous metals (usually 304 stainless steel or copper‐nickel) and are resistant to the corrosive effects of hot water.

Key Features and Benefits

  • Welded carbon steel vessel designed and built‐in strict accordance with the ASME Code Section VIII and stamped, certified, and registered with the National Board of Boiler and Pressure Vessel Inspectors. 
  • Complies with NSF/ANSI 61 Annex G, NSF/ANSI 372 and conforms with lead content requirements for “lead‐free” plumbing as defined in the U.S. Safe Drinking Water Act.
  • Heavy duty insulation and jacketing available for maximum operating efficiency and minimal stand‐by heat loss.
  • Standard full five (5) year tank warranty.
  • Optional extended warranties.
  • Optional connections, coatings, and exterior tank insulation are also available. For hot water storage tanks, exterior insulation is a cost-effective way to reduce energy consumption while maintaining the desired temperature with minimal heat losses.
  • All reco storage tanks  are available in vertical and horizontal configurations with storage capacities up to 35,000 gallons. Each reco storage tank includes separate connections for a relief valve, temperature sensor, spare instrumentation, and drain as standard. A 12″ x 16″ manway is included with each tank as well.
  • We use NSF Standard 61 certified cement lining that was specifically developed to protect steel surfaces from the corrosive effects of hard or soft water at higher temperatures. It provides excellent protection and is fully field repairable. We avoid glass linings, as they require a sacrificial anode for corrosion protection and must be handled with extreme care as they are very fragile and not field repairable.
